Setup JBoss on Red Hat Enterprise Linux 5 (RHEL5) Server

jbosslogoA recent task required an installation and setup of a JBoss Application Server on a Linux box. I origianlly selected the Ubuntu 8.0.4 LTS Server Edition for this task since I have had a little more experience with Ubuntu. I have graduated to Red Hat Enterprise Linux 5.2 (RHEL) and CentOS 5.2. I created A RHEL virtual machine with VMware Workstation. I started from scratch, as too many guides make too many assumptions in their build. I am new to this, and this is what worked for me. JBoss requires JAVA JDK 1.4+ to run. This virtual machine installation is RHEL with GDE.

Installation Instructions
Please note, that these instructions worked for me as I am still learning the best practices and standards for software installations. In other words, there may be a more likely location to copy the files however, this procedure works. With that in mind …

  • Install JDK (Java Development Kit)
    Please refer to my earlier post that details this installation.
  • Download JBoss Application Server
    I used the latest Stable release, version 4.2.3.GA.
    jbossrhel1
  • Press Download
    jbossrhel2
  • Then select jboss-4.2.3.GA.zip
  • After the download is complete, use Computer, go to Filesystem, usr, lib
    jbossrhel3
  • Create a folder jboss
    jbossrhel4
  • Drag jboss-4.2.3.GA.zip to the folder /usr/lib/jboss
    jbossrhel5
  • Double-click jboss-4.2.3.GA.zip
    jbossrhel6
  • Press extract and choose All Files to the folder jboss
    jbossrhel7
  • In the jboss folder, press run.sh, and when prompted select Run in Terminal.
    jbossrhel9
  • The terminal window will look like the following if all went well.
    jbossrhel8
  • By default jboss will run and only be accessible as 127.0.0.1 and not available to any other connection.
    jbossrhel10
  • So that JBoss Application Server will be available outside of 127.0.0.1 a bind needs to be made. When launching JBoss in Terminal or with a link, use the following commands:

    cd /usr/lib/jboss/jboss-4.2.3.GA/bin
    ./run.sh -b 192.168.1.55 all

    Note: change the IP address to your IP address.

  • To have the JBoss Application Server be part of a cluster, use the following commands instead.

    cd /usr/lib/jboss/jboss-4.2.3.GA/bin
    ./run.sh -c all -Djboss.bind.address=192.168.1.55

The results of the command switches from another workstation:

jbossrhel11

I really couldn’t go into much detail behind the command line switches, however these switches work, one could always refer to internet documentation. Some useful documentation.
